Cross-check - synchronized schematic and PCB browsing.Good news, Fusion 360 fans - Autodesk just announced that they won’t be removing support for STEP file exports for personal use licensees of the popular CAD/CAM platform after all.Īs we noted last week, Autodesk had announced major changes to the free-to-use license for Fusion 360.
Automatic error checking of your Gerber-generated netlist against the IPC-356 netlist test file.
Browsing by component, pin and netlist that lets you instantly inspect any design element.
Simplified (Free) or realistic ( Premium). If IPC-356 netlist file has been imported:
An export of the 3D board shape and external layers to a STEP file, to be read into any mechanical CAD.
A measurement function that shows you the X,Y,Z and XY distances between any two points (pad, edge or hole).
Material density, hollowing and layer spread controls that let you “look between the layers” and verify connections between them.
Layer ON/OFF and PEEL functions, which let you remove any design layers that are in your way.
Color scheme selection that lets you assign colors to structures in different ways.
Orthogonal camera mode, allowing for a homogeneous scale, 1:1 printout and 2D mode navigation, just like in a standard Gerber Viewer.
Full 3D navigation via intuitive mouse and keyboard controls, so you can quickly and easily view any point on the board from any angle you choose.
Realistic 3D rendering from your Gerber files that shows you just how your finished board will look and unveils errors that are difficult to detect in a 2D view.
It makes pre-production verification of your PCB designs fast, easy, intuitive and fun. ZofzPCB lets you see inside your board – between the layers – so you can give it a truly thorough inspection. ZofzPCB is a FREE 3D Gerber viewer that shows you more than just how your board is going to look.
Be able to “look between the layers” for hidden errors?Ī Gerber Viewer that Gets “Between the Layers”.
Inspect it from any angle… just like holding the finished board in your hand?.
See your board just as it will look when it comes back from production?.
Get a completely different perspective than you get from CAD or a 2D Gerber viewer?.
Look at your PCB design through a different set of eyes?.
Of course, with experience and as you gain confidence in your CAD package, un-caught errors become less likely. So it's hard to visualize your finished board. Plus, your CAD program generates some structures automatically – you don't see them while you're in CAD. You're dealing with multiple layers, so you can't see everything at once. You also know how difficult it is to really check everything in CAD. It's costly – and embarrassing – to find design errors in a production board. If you're a PCB electronics designer, you know how important it is to review your designs thoroughly before sending them to manufacturing.
